• Toggle Type Plastic Injection Molding Machine
Toggle Type Plastic Injection Molding Machine Toggle Type Plastic Injection Molding Machine Toggle Type Plastic Injection Molding Machine
Toggle Type Plastic Injection Molding Machine
Toggle Type Plastic Injection Molding Machine
STANDARD FEATURES OF CLAMPING UNIT
  • Tie bars are nitrified to present high rigidity and better wear resistance.
  • The 5-point vertical toggle mechanism aims to perform fast mould open/close, longer clamping stroke and stabilize movement of clamping mechanism.
  • The standard hydraulic design of fast mould close is for shortening dry cycle time and saving power.
  • Low-pressure protection is to ensure good protection of contact surface.
  • Clamping stroke is precisely calculating by linear transducer to have high accuracy of position.
  • Integrated hydraulic circuit is to reduce oil temperature and efficiency loss.
  • Injection and clamping controlled by multiple pressures and speeds ensure easy setting and accurate processing
  • High-rigid frame structure assures stable and smooth sliding movement and precision molding
  • High torque screw motor ensures superior plasticizing ability for plastic
  • Professional designed screw and barrel, suitable for various plasticizing demands

This model is most economic type, and can produce various plastic products.
Our machine quality is stable and durable, there are model from 90 ton to 700 ton for selection.


Suitable electricity: AC 220V 60Hz         Specification subject to change without notice



Suitable electricity: AC 220V 60Hz         Specification subject to change without notice
